Decodio RED (Signals Analysis Software and PMR Decoding)

Decodio RED is our flagship software, provides core signal processing and decoding features to enable advanced analysis using various hardware components. SIGNAL ACQUISITION General-purpose spectrum analyzers or RF receivers are used to acquire baseband IQ data with an instantaneous bandwidth of up to 200 MHz. Multiple receivers can be used in parallel to increase the working bandwidth. SIGNAL EXTRACTION, RECORDING AND STREAMING Narrow-band channel extraction, demodulation and decoding is performed using modern software-defined radio techniques running on a conventional computer. The maximum number of decoded channels depends only on the available CPU power. Typically, on a modern desktop PC, up to 512 channels of arbitrary bandwidths can be processed in real-time, including extraction, recording and decoding. Server-grade hardware further extends the number of channels which can be processed in parallel. SIGNAL ANALYSIS Decodio RED combines manual signal analysis functionalities with automatic emission detection and classification in an easy-to-use interface. Time and frequency domain measurements as well as burst analysis are done intuitively using overlays and markers, allowing the operator to quickly respond to changes in the RF environment. DIGITAL PMR SUPPORT Besides the standard analog modulations, full support for TETRA, Tetrapol, DMR, dPMR, NXDN, P25 and D-STAR is available, including broadcast parameters, metadata as well as voice and data decoding. Optional modules for encrypted content handling are also available.
